SP-6820

• Wiegand and RS232 (simultaneous)
• 6" to 8" (15 to 20cm) read range
• 4.6" x 3.1" x 0.65" (11.7 x 7.9 x 1.7cm) in size
• Power requirement: 5 to 12 VDC
• Single Gang Box Mount; Customizable Tri-state LED
• Credentials (Cards/Tags)

AWID’s Proximity Reader SP-6820 is specially suited for applications where a discriminating look makes a difference. An attractive package which looks great outside the Board room or at the front gate in the rain or snow. With a read range of 6 to 8 inches, the SP-6820 delivers exceptional value without compromise on quality, durability, or performance for both indoor and outdoor applications.The SP-6820 reader is a fully featured Wiegand and RS-232 compatible reader with an LED and Annunciator for both small and large volume OEM and Dealer installations. It is designed to mount on a standard-single-gang electric wall-box or on the surface of an interior or exterior wall.

Features

• Read range of 6 to 8 inches
• Specially designed for attractive appearance
• Electronics potted with epoxy compound for demanding environmental applications
• LED for visual feedback, Piezo beeper for audio feedback
• Compatible with all Wiegand access control systems
• Industry standard Wiegand (26 to 50 bit) output and RS-232 interface
• Attractive high-tech enclosure with dark gray or beige color

Benefits

• Ease of use and entry. Assures long life of cards by eliminating need to physically swipe card against reader
• Elegantly and beautifully mounted
• Reader electronics protected against application elements to assure long reader life.
• Visual and Audible indicators providing dependable user feedback and guidance for quick and easy installation
• Wiegand output allows use of multiple control panels allowing stocking of one reader for all applications and credential requirements
• Choice of color matching settings
